SPINE Documentation
Introduction
Scalable Particle Imaging with Neural Embeddings (SPINE) is a machine-learning reconstruction toolkit for particle imaging detectors, developed primarily for Liquid Argon Time Projection Chambers (LArTPCs). It combines configuration-driven I/O, deep neural network models, object construction, post-processing, analysis, and visualization into a single reconstruction workflow.
For full reconstruction, training, and inference workflows, SPINE is intended to run from the published SPINE container image released alongside each SPINE version. Use the release-tagged image ghcr.io/deeplearnphysics/spine:<release> when reproducibility matters. When in doubt, use ghcr.io/deeplearnphysics/spine:latest or omit the tag entirely, which is equivalent in Docker-style image references. Docker is the usual path on local machines; Apptainer or Singularity is the usual path on HPC systems. A local pip installation is most appropriate when you only need post-processing, analysis, visualization, or lightweight data inspection.
The package is organized around the spine.driver.Driver pipeline:
load detector inputs and labels
run neural network inference or training
unwrap batched outputs
construct fragments, particles, and interactions
apply post-processing and detector matching
run analysis scripts and write results
Getting Started
The landing page should stay short and decision-oriented. The detailed setup and workflow instructions live in the dedicated guides linked below.
Installation
For complete SPINE workflows, start from the released SPINE container image:
# Equivalent to omitting the tag entirely
docker pull ghcr.io/deeplearnphysics/spine:latest
# Use an explicit release tag when you want a pinned runtime
docker pull ghcr.io/deeplearnphysics/spine:<release>
On HPC systems, pull the same released image through Apptainer or Singularity:
# Equivalent to omitting the tag entirely in the Docker image reference
apptainer pull spine_latest.sif docker://ghcr.io/deeplearnphysics/spine:latest
# Or pin to a specific release
apptainer pull spine_<release>.sif docker://ghcr.io/deeplearnphysics/spine:<release>
For local pip installs, development workflows, and the full runtime discussion, see Installation.
Quick Start
For the most direct end-to-end path, run SPINE from the released container with a configuration file:
# Using the newest published image
docker run --gpus all -v $(pwd):/workspace \
ghcr.io/deeplearnphysics/spine:latest \
spine --config /workspace/config/train_uresnet.yaml --source /workspace/data.h5
# Or use a pinned release image
docker run --gpus all -v $(pwd):/workspace \
ghcr.io/deeplearnphysics/spine:<release> \
spine --config /workspace/config/train_uresnet.yaml --source /workspace/data.h5
On Apple Silicon macOS systems, pass --platform=linux/amd64 to docker
run when using the published SPINE image. For Jupyter notebook/lab use,
avoid the Docker Desktop combination of Apple Virtualization Framework with
Rosetta enabled; Apple Virtualization Framework without Rosetta and Docker VMM
have both been verified to work.
If you want to inspect one entry interactively, the Python entry point looks like this:
from spine.config import load_config_file
from spine.driver import Driver
from spine.vis.out import Drawer
cfg = load_config_file("/workspace/config/train_uresnet.yaml")
driver = Driver(cfg)
data = driver.process(entry=0)
drawer = Drawer(data, draw_mode="both")
fig = drawer.get("particles")
fig.show()
For the full interactive-container workflow, Apptainer examples, and the longer Python walkthrough, see Quick Start.
SPINE also exposes lower-level modules for data structures, model components, construction, analysis, math helpers, and visualization, but the main user-facing workflow starts from the driver and configuration system.
